Description
The BlackStar 100F80 LH is a 100 pitch QD roller chain sprocket with 80 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a QD Type F Bushing (sold separately).
| Specifications | |
|---|---|
| Part Number | 100F80 LH |
| Chain Pitch | 100 |
| Number of Teeth | 80 |
| Maximum Bore | 3-15/16" |
| Bore Type | QD |
| Hub Style | QD |
| Bushing Required | QD Type F Bushing |
| Strand Count | Single |
| Material | Steel |
| Outside Diameter | 32.57" |
| Pitch Diameter | 31.839" |
| Approx. Weight | 123.0 lbs |

Bushing Required
This sprocket requires a QD Type F Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Cross-references: Browning 100F80, Martin 100F80
