BlackStar D140BS13H 3 K2S - Double Strand 140 Pitch Finished Bore Sprocket - 13 Tooth - 3" Bore


Price:
$ 499.61

Description

The BlackStar D140BS13H 3 K2S is a 140 pitch double strand Finished Bore roller chain sprocket with 13 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket has a 3" bore with keyway and set screws and is ready for immediate installation.

Specifications
Part Number D140BS13H 3 K2S
Chain Pitch 140
Number of Teeth 13
Bore Size 3"
Bore Type Finished Bore (Keyway + Set Screws)
Hub Style Finished Bore
Strand Count Double
Material Steel
Outside Diameter 8.15"
Pitch Diameter 7.313"
Approx. Weight 25.200 lbs
BlackStar D140BS13H 3 K2S Sprocket Spec Sheet

Cross-references: Browning DH140B13, Martin D140BS13, Boston Gear DRS140B13
