BlackStar H100B24 - 100 Pitch B-Hub Sprocket - 24 Tooth


Price:
$ 107.41

Description

The BlackStar H100B24 is a 100 pitch B-Hub roller chain sprocket with 24 teeth, precision manufactured from SAE 1045 steel with induction-hardened teeth for extended wear life and features machine-cut tooth profiles for smooth, reliable chain engagement.

Specifications
Part Number H100B24
Chain Pitch 100
Number of Teeth 24
Minimum Bore 1-1/4"
Maximum Bore 3"
Bore Type Plain Bore
Hub Style B-Hub
Strand Count Single
Material Steel
Hardened Teeth Yes
Outside Diameter 10.25"
Pitch Diameter 9.576"
Approx. Weight 19.2 lbs
BlackStar H100B24 Sprocket Spec Sheet

Cross-references: Browning H100B24, Martin 100BS24, Boston Gear RS100B24
