Description
The BlackStar H100F30 is a 100 pitch QD roller chain sprocket with 30 teeth, precision manufactured from SAE 1045 steel with induction-hardened teeth for extended wear life and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a QD Type SF Bushing (sold separately).
| Specifications | |
|---|---|
| Part Number | H100F30 |
| Chain Pitch | 100 |
| Number of Teeth | 30 |
| Bore Type | QD |
| Hub Style | QD |
| Bushing Required | QD Type SF Bushing |
| Strand Count | Single |
| Material | Steel |
| Hardened Teeth | Yes |
| Outside Diameter | 12.64" |
| Pitch Diameter | 11.959" |
| Approx. Weight | 30.200 lbs |

Bushing Required
This sprocket requires a QD Type SF Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.
