Description
The BlackStar H50P32 OEM is a 50 pitch Taper Lock roller chain sprocket with 32 teeth, precision manufactured from SAE 1045 steel with induction-hardened teeth for extended wear life and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a Taper Lock Bushing (sold separately).
| Specifications | |
|---|---|
| Part Number | H50P32 OEM |
| Chain Pitch | 50 |
| Number of Teeth | 32 |
| Bore Type | QD |
| Hub Style | Taper Lock |
| Bushing Required | Taper Lock Bushing |
| Strand Count | Single |
| Material | Steel |
| Hardened Teeth | Yes |
| Outside Diameter | 6.72" |
| Pitch Diameter | 6.376" |
| Approx. Weight | 3.45 lbs |

Bushing Required
This sprocket requires a Taper Lock Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Cross-references: Martin 50TB32, Browning 50TB32
Compatible Components
Matched Roller Chain
- Lynx A2050 RIV 50' - Extended Pitch Chain 50ft Reel
- Lynx A2050 RIV 50' - Extended Pitch Chain 50ft Reel
- Lynx HD08B RIV 50' - British Standard Chain 50ft Reel
- Lynx HD08B RIV 50' - British Standard Chain 50ft Reel
Matched Roller Chain
- Lynx A2050 RIV 50' - Extended Pitch Chain 50ft Reel
- Lynx A2050 RIV 50' - Extended Pitch Chain 50ft Reel
- Lynx HD08B RIV 50' - British Standard Chain 50ft Reel
- Lynx HD08B RIV 50' - British Standard Chain 50ft Reel
Matched Roller Chain
- Lynx A2050 RIV 50' - Extended Pitch Chain 50ft Reel
- Lynx A2050 RIV 50' - Extended Pitch Chain 50ft Reel
- Lynx HD08B RIV 50' - British Standard Chain 50ft Reel
- Lynx HD08B RIV 50' - British Standard Chain 50ft Reel
Not sure what fits? Call (888) 203-2358 and we will match it from the Houston warehouse.
